767
RJ-10A
Capacity: 4,500kg（10,000lbs）
It is the heavy-duty design Rolling Jack for tire service.
Especially recommend for use with the 4-post and scissor lifts with capacity more than 8Ton（18,000lbs).
Product has been successfully added to cart
Shopping Cart Total kinds of merchandise
| Model | | RJ-10A |
| Lifting Capacity | | 4500kg (10,000 lbs) |
| Lifting Time | | 50s |
| Arm Pads Reach | A | 980-1684mm (35 5/8-66 1/4”) |
| Min.Height | B | 270mm (10 5/8") |
| Support Base Width | C | 980-1435mm (35 5/8"-56 1/2") |
| Min.rubber pad Height | D | 273mm (10 3/4") |
| Max. Lifting Height (Without adapters) | E | 550mm (21 5/8") |
| Max. Lifting Height (With adapters) | | 779mm (30 5/8") |
| Overall Width | F | 550mm (21 5/8”) |
| Air Pressure | | 0.8Mpa |
| Pump | | Pneumatic Pump |
Gross weight for RJ-10A: 200kgs
