414AE
Heavy Duty Alignment Service Four Post Lift
Maximize your profit
From passenger cars to to long wheelbase commercial vehicles, PEAK 414AE handles efficiently for both general and alignment services. Choose PEAK 414AE, to enhance your business and to maximize your profit.
Product has been successfully added to cart
Shopping Cart Total kinds of merchandise
• Electric-air control operation system.
• Mechanical self-lock and air-drived safety release.
• Electrical hydraulic power system, cable-drived.
• Dual safety devices mechanism: both primary safety locks and cable-slack protection system.
• Non-skid diamond platforms.
• Stepless adjustable width between platforms.
• Adjustable turnplate pockets to fit various wheel bases.
• Optional Jack and Turnplate.
| Model 414AE | | ALIGNMENT FOUR-POST LIFT |
| Lifting Capacity | | 6500kg (14,000lbs) |
| Lifting Time | | 81s |
| Overall Length (Inc Ramps) | A | 7252mm (285 1/2") |
| Overall Length (No Ramps) | B | 6224mm (245") |
| Overall Width | C | 3324mm (130 7/8") |
| Width Between Columns | D | 2946mm (116") |
| Max.Lifting Height | E | 1950mm (76 3/4") |
| Max. Lock Height to top of runway | 1880mm (74") |
| Overall Height | F | 2189mm (86 1/4") |
| Minimum Height | G | 250mm (9 7/8") |
| Max.Underneath Height | H | 1730mm (68 1/8") |
| Max. Lock Underneath runway | 1660mm (65 3/8") |
| Drive-Thru Clearance | I | 2592mm (102") |
| Width Between Runways | J | 1194mm(47")
Min.85mm（3 3/8")~
Max.1385mm (54 1/2") |
| Outside Edge of Runways | K | 2210mm (87")
Min.1101mm(43 3/8")~
Max.2401mm (94 1/2") |
| Min. Four Wheel Align | L | 2396mm (94 11/32") |
| Max. Four Wheel Align | M | 4310mm (169 11/16") |
| Max. Two Wheel Align | N | 5190mm (204 11/32") |
| Gross Weight | | 1634kg (3,602 lbs) |
| Motor | | 3.0 HP |
