850
407-HP
4-POST PARKING LIFT
Commercical Grade 4-post Parking Lift for Car,Van and SUV.Similar to model 407-P,but higher. 407-HP is 330mm(13” ) higher in lifting than 407-P.
Product has been successfully added to cart
Shopping Cart Total kinds of merchandise
• 3000kg lifting capacity.
• PEAK exclusive hidden safety locks and manual single-point lock release.
• Double-
shaped columns for increased strength.
• Non-slip platform.
• Optional parts: plastic drip trays, jack tray, caster kits.
• Flexible Design: power side column can be installed at any corner.
| Model 407-HP | | 4-Post Parking Lift |
| Lifting Capacity | | 3000kg(6,600lbs) |
| Lifting Time | | 37s |
| Overall Length (Inc Ramps) | A | 5008mm (197 1/8") |
| Outside edge of crossbeams | B | 3987mm (157") |
| Overall Width | C | 2409mm (94 7/8") |
| Width Between Posts | D | 2167mm (85 3/8") |
| Max.Lifting Height | E | 2202mm (86 3/4") |
| Max locking height | 2122mm (83 9/16") |
| Overall Height | F | 2455mm (96 5/8") |
| Minimum Height | G | 135mm (5 3/8") |
| Max.Underneath Height | H | 2102mm (82 3/4") |
| Max. Lock Underneath runway | 2022mm (79 5/8") |
| Drive-Thru Clearance | I | 1956mm(77") |
| Width Between Runways | J | 940mm (37") |
| Outside Edge of Runways | K | 1890mm(74 3/8") |
| Gross Weight | | 690kg |
| Motor | | 3.0HP |
